Rated current(Amperes) 額定電流(安培)

350A

Voltage Ratings (Volts) 額定電壓(伏特)

600V

Contact Barrel Wire Size[AWG]導線尺寸[AWG]

                                      mm²

2/0 to 300mcm

67.4 to 152mm²

Maximum Wire Insulation Diameter[inches] 最大導線絕緣直徑[inches]

                                                            mm

1.1inches

27.9mm

AVG Contact Resistance(micro-ohms) 平均接觸電阻(微歐)

50

Insulation Withstanding   Test Voltage (Volts AC/DC) 絕緣耐電壓（伏交流/直流）

2200V

Contact Retention Force (lbf)  端子保持力(磅)

500lbf

Life壽命

a.     No load (Contact/Disconnect Cycles)

無負載(端子插拔次數(shù))

b.     under Load (Hot Plug 250 cycles @ 120V)

帶負載(120V熱插拔250次)

To 10,000

100A

AVg. Connection/Disconnect (lbf) 平均插拔力(磅)

30lbf

operating Temperature Range °C  工作溫度范圍 °C

                                              °F

-20 °to 105 °

-4 °to 221 °

Flammability Rating of Housing Material 外殼防火等級

UL 94-V0

Contact Material 端子材料

Silver plated copper 銅鍍銀
